| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 705-11-34011 | PUMP ASSEMBLY (SAL50) | 1 | ||||
| ? | 705-17-02011 | • BRACKET ASSEMBLY | 1 | F1 | |||
| ? | 705-17-02353 | • • BUSHING | 1 | ||||
| ? | 705-17-34012 | • CASE. GEAR | 1 | F1 | |||
| ? | 705-17-02122 | • CARRIER | 1 | F1 | |||
| ? | 705-17-02353 | • • BUSHING | 1 | ||||
| ? | 705-17-34411 | • GEAR, DRIVE | 1 | F1 | |||
| ? | 705-17-34512 | • GEAR, DRIVEN | 1 | F1 | |||
| ? | 705-17-02612 | • PLATE, SIDE | 2 | ||||
| ? | 705-17-02440 | • RING, BACK-UP | 2 | ||||
| ? | 705-17-02472 | • RING, SEAL | 2 | ||||
| ? | 705-17-02381 | • O-RING | 2 | ||||
| ? | 04020-01024 | • PIN, DOWEL | 4 | ||||
| ? | 705-17-02770 | • BOLT | 4 | ||||
| ? | 01643-51232 | • WASHER | 4 | ||||
| ? | 705-17-02870 | • PLATE | 1 | ||||
| ? | 705-17-02830 | • SEAL, OIL | 1 | ||||
| ? | 04065-04018 | • RING, SNAP | 1 | ||||
| ? | |||||||
| ? | F1 - PARTS ARE SUPPLIED SEPARATELY ONLY TO DESIGNATED | ||||||
| ? | DEALERS WHICH ARE EQUIPPED WITH A HYDRAULIC PUMP | ||||||
| ? | TESTER. |
