| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HEATER ASSEMBLY, EAGLE (SEE PG 05-092) | -29 | 05-092 | ||||
| ? | 01010-51052 | BOLT, MOUNT HEATER | 3 | ||||
| ? | 01643-31032 | WASHER | 3 | ||||
| ? | 01010-51030 | BOLT | 2 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | (NSS) | SPACER | 2 | ||||
| ? | 416-942-A550 | COVER | 1 | ||||
| ? | 01010-50616 | BOLT, COVER | 2 | ||||
| ? | 01602-20619 | WASHER, LOCK | 2 | ||||
| ? | 416-942-1530 | GROMMET, HEATER HOSES | 1 | ||||
| ? | 416-942-1871 | PLATE | 1 | ||||
| ? | 01010-50825 | BOLT, PLATE | 2 | ||||
| ? | 01643-30823 | WASHER | 2 | ||||
| ? | 416-942-1622 | BRACKET | 2 | ||||
| ? | 01010-50825 | BOLT, BRACKET | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 416-942-1771 | BRACKET, WELDED TO FLOOR | 1 | ||||
| ? | 416-942-1710 | BRACKET, WELDED TO REAR MAIN FRAME | 1 |
