| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-57-11211 | SEAT ASSEMBLY, RIGID TYPE | 1 | ||||
| ? | 417-57-11220 | • SEAT ASSEMBLY | 1 | ||||
| ? | 417-57-11250 | • • CUSHION, BACK | 1 | ||||
| ? | 423-57-11490 | • • BRACKET | 1 | ||||
| ? | 423-57-11380 | • • SCREW, MOUNT BRACKET TO BACK CUSHION | 2 | ||||
| ? | 417-57-11260 | • • CUSHION, SEAT | 1 | ||||
| ? | 423-57-11650 | • • SPRING | 1 | ||||
| ? | 423-57-11330 | • • BRACKET, RECLINING | 1 | ||||
| ? | 423-57-11380 | • • SCREW, MOUNT RECLINER BRACKET TO BACK AND SEAT | 2 | ||||
| ? | 423-57-11371 | • • COVER, RECLINING BRACKET | 1 | ||||
| ? | 423-57-11160 | • • SCREW, MOUNT COVER | 1 | ||||
| ? | 423-57-11420 | • • BUSHING | 1 | ||||
| ? | 423-57-11430 | • • SCREW, BRACKET TO SEAT CUSHION | 1 | ||||
| ? | 423-57-11440 | • • WASHER | 1 | ||||
| ? | 423-57-11360 | • • LEVER | 1 | ||||
| ? | 423-57-11410 | • • SCREW, MOUNT LEVER | 1 | ||||
| ? | 423-57-11350 | • • SLIDE, LH | 1 | ||||
| ? | 417-57-11270 | • • SLIDE, RH | 1 | ||||
| ? | 423-57-11390 | • • BOLT, SEAT ASSEMBLY TO SLIDES | 4 | ||||
| ? | 417-57-11231 | • ARM REST ASSEMBLY, LH | 1 | ||||
| ? | 417-57-11241 | • ARM REST ASSEMBLY, RH | 1 | ||||
| ? | 417-57-11112 | SUPPORT, MOUNTING | 2 | ||||
| ? | 01580-10806 | NUT, MOUNT SLIDES TO SUPPORTS | 4 | ||||
| ? | 01643-30823 | WASHER | 4 | ||||
| ? | 01010-51225 | BOLT, MOUNT SUPPORTS TO FLOOR | 4 | ||||
| ? | 01643-31232 | WASHER | 4 |
