| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SEAT BELT (SEE PG 05-038) | -29 | 05-038 | ||||
| ? | SEAT ASSEMBLY (SEE PG 05-038) | -29 | 05-038 | ||||
| ? | 423-57-A1490 | SCREW, SOCKET BUTTON HEAD - SEAT MOUNTING | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 423-57-A1200 | ARM REST KIT | 1 | ||||
| ? | (NSS) | • REST, ARM - LH | 1 | ||||
| ? | (NSS) | • REST, ARM - RH | 1 | ||||
| ? | (NSS) | • BOLT, 5/16NC X 2 1/2 - THREAD FORMING | 4 | ||||
| ? | (NSS) | • SPACER | 4 |
