| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6742-01-3780 | BOLT - M12 X 1.75 X 50 | 4 | ||||
| ? | 6732-21-3160 | SCREW, ROUND HEAD - M5 X 0.80 X 17 | 2 | ||||
| ? | 6732-21-3140 | PIN, TIMING | 1 | ||||
| ? | 6732-21-3150 | RING, RETAINING | 1 | ||||
| ? | 6732-21-3870 | SEAL, O-RING | 1 | ||||
| ? | 6732-21-3180 | HOUSING, TIMING PIN | 1 | ||||
| ? | 6732-21-3880 | SEAL, RECTANGULAR RING | 1 | ||||
| ? | 6736-21-5310 | BOLT - M8 X 1.25 X 16 | 16 | ||||
| ? | 6742-01-0580 | HOUSING, GEAR | 1 | ||||
| ? | 6742-01-1030 | GASKET, GEAR HOUSING | 1 | ||||
| ? | 6742-01-0540 | BOLT - M8 X 1.25 X 20 | 5 | ||||
| ? | 6742-01-0550 | KIT, FRONT GEAR COVER SERVICE | 1 | F1 | |||
| ? | (NSS) | • SEAL, OIL | 1 | ||||
| ? | 1307 191 H1 | COVER, GEAR | 1 | ||||
| ? | 6742-01-0530 | BOLT - M8 X 1.25 X 50 | 6 | ||||
| ? | 6742-01-3320 | SHIELD, DUST | 1 | ||||
| ? | |||||||
| ? | F1 - INCLUDES INSTALLATION TOOLS. | ||||||
| ? |
