| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 425-963-AB90 | COIL, HEATER | 1 | F1 | |||
| ? | 425-963-AA40 | VALVE, WATER | 1 | ||||
| ? | 425-963-AA80 | FITTING, 90 DEGREE | 2 | ||||
| ? | 425-963-AD40 | CABLE ASSEMBLY, WATER VALVE | 1 | ||||
| ? | HOSE, HEATER COIL TO WATER VALVE - 5/8 ID., 4 IN | ||||||
| ? | LONG | 1 | F3 | ||||
| ? | HOSE, FITTING TO HEATER COIL - 5/8 ID., | ||||||
| ? | 15 1/2 IN. LONG | A/R | F3 | ||||
| ? | HOSE, WATER VALVE TO FITTING - 5/8 ID., 22 IN | ||||||
| ? | LONG | 1 | F3 | ||||
| ? | 425-963-A870 | CLAMP, HOSE | 6 | ||||
| ? | 425-963-AA20 | FITTING, 90 DEGREE 5/8 SPLICER | 2 | ||||
| ? | INSULATION - 3 IN. LONG | 2 | F2 | ||||
| ? | 425-963-A850 | BOLT, TORX TRUSS - 10-32 X 1/2 IN | 4 | ||||
| ? | 425-963-A680 | COVER, COIL WELDMENT | 1 | ||||
| ? | 425-963-AE20 | KNOB | 1 | ||||
| ? | |||||||
| ? | F1 - USED ON MACHINES S/N 4025 AND UP. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - CUT FROM BULK INSULATION 425-963-AF20. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F3 - CUT FROM BULK HOSE 364 359 C1. | ||||||
| ? |
