| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 425-963-A640 | COVER, TOP WELDMENT | 1 | F1 | |||
| ? | 425-963-AC70 | SWITCH, A/C PUSH BUTTON - EARLY VERSION | 1 | F3 | a | ||
| ? | 425-963-AC71 | SWITCH, A/C PUSH BUTTON - CURRENT VERSION | 1 | b | |||
| ? | 425-963-AF50 | • LAMP, A/C PUSH BUTTON SWITCH | 1 | ||||
| ? | 425-963-AC60 | DECAL, SWITCH PANEL | 1 | ||||
| ? | FOAM, COVER | 4 | F2 | ||||
| ? | 425-963-AD50 | CABLE ASSEMBLY, RECIRCULATING AIR DOOR | 1 | ||||
| ? | 425-963-A950 | SWITCH, FAN | 1 | ||||
| ? | 425-963-A930 | NUT, JAM - 7/16-28 | 1 | ||||
| ? | 425-963-A810 | KNOB, FAN CONTROL | 1 | ||||
| ? | 425-963-AE20 | KNOB, RECIRCULATING AIR DOOR CONTROL | 1 | ||||
| ? | |||||||
| ? | F1 - USED ON MACHINES S/N 4025 AND UP. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - CUT TO FIT FROM BULK FOAM 425-963-AE80. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F3 - ORDER SWITCH 425-963-AC71. | ||||||
| ? |
