| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 423-57-A2100 | SEAT, SUSPENSION TYPE | 1 | ||||
| ? | 423-57-A2410 | • UPPER ASSEMBLY | 1 | ||||
| ? | 423-57-A2420 | • KIT, BACK COVER | 1 | F1 | |||
| ? | 206-57-A1430 | • FOAM, BACK | 1 | ||||
| ? | 423-57-A2430 | • COVER, SEAT | 1 | ||||
| ? | 206-57-A1450 | • FOAM, SEAT | 1 | ||||
| ? | 206-57-A1460 | • KIT, SEAT FRAME | 1 | F1 | |||
| ? | 206-57-A1470 | • ADJUSTMENT KIT, CABLE | 1 | F1 | |||
| ? | 206-57-A1480 | • SPRING KIT, HEIGHT RISER | 1 | F1 | |||
| ? | 206-57-A1490 | • LATCH KIT, HEIGHT RISER | 1 | F1 | |||
| ? | 206-57-A1510 | • DAMPER KIT | 1 | F1 | |||
| ? | 206-57-A1520 | • SUSPENSION ASSEMBLY | 1 | ||||
| ? | 206-57-A1530 | • ADJUSTMENT KIT, FORWARD / BACKWARD | 1 | F1 | |||
| ? | 206-57-A1540 | • ADJUSTMENT KIT WEIGHT | 1 | F1 | |||
| ? | 206-57-A1550 | • STOP KIT, BUMPER | 1 | F1 | |||
| ? | 206-57-A1560 | • HANDLE KIT | 1 | F1 | |||
| ? | 206-57-A1570 | • HEIGHT RISER KIT | 1 | F1 | |||
| ? | 206-57-A1580 | • COVER KIT, SUSPENSION | 1 | F1 | |||
| ? | 206-57-A1590 | • SLIDERAIL KIT | 1 | F1 | |||
| ? | 206-57-A1610 | • BEARING KIT, SUSPENSION | 1 | F1 | |||
| ? | 425-57-A1110 | RISER - MOUNT SEAT TO FLOOR | 2 | ||||
| ? | 01435-01225 | BOLT, MOUNT RISERS TO CAB FLOOR | 4 | ||||
| ? | 423-54-A1110 | PLATE | 1 | ||||
| ? | 01010-80820 | BOLT | 2 | ||||
| ? | |||||||
| ? | F1 - ALL KITS HAVE REQUIRED MOUNTING HARDWARE. | ||||||
| ? |
