| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-57-A1120 | SEAT ASSEMBLY, OPERATOR'S | 1 | ||||
| ? | 01640-21123 | • WASHER | 4 | ||||
| ? | 01643-31032 | • WASHER | 4 | ||||
| ? | 02010-20625 | • BOLT | 2 | ||||
| ? | 02011-20502 | • BOLT | 2 | ||||
| ? | 423-57-A1290 | • SPACER | 2 | ||||
| ? | 423-57-A1370 | • WASHER, RECTANGULAR | 4 | ||||
| ? | 423-57-A1380 | • WASHER, RUBBER | 6 | ||||
| ? | 423-57-A1390 | • CABLE | 2 | ||||
| ? | 423-57-A1410 | • BELT, SEAT | 1 | ||||
| ? | 423-57-A1420 | • NUT, PUSH-ON | 4 | ||||
| ? | 423-57-A1440 | • BRACKET, L.H | 1 | ||||
| ? | 423-57-A1450 | • BRACKET, R.H | 1 | ||||
| ? | 423-57-A1460 | • NUT, CENTERLOCK - 3/8 UNC | 2 | ||||
| ? | 423-57-A1470 | • NUT, CENTERLOCK - 7/16 UNC | 2 | ||||
| ? | 423-57-A1480 | • SPACER | 2 | ||||
| ? | 423-57-A1510 | • KNOB, BACK REST TILT | 1 | ||||
| ? | 423-57-A1520 | • KNOB, SEAT TILT | 1 | ||||
| ? | 423-57-A1530 | • PIN, SPIROL | 1 | ||||
| ? | 421-57-A1130 | • SEAT ASSEMBLY | 1 | ||||
| ? | • SUSPENSION, SEAT (SEE PG 05-056) | -29 | 13BHW320.003 |
