| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 424-54-13411 | HOOD | 1 | ||||
| ? | 424-54-14532 | SHEET | 1 | ||||
| ? | 423-54-11682 | SHEET, L.H | 1 | ||||
| ? | 423-54-11672 | SHEET, R.H | 1 | ||||
| ? | 424-54-14542 | SHEET | 2 | ||||
| ? | 424-54-14582 | SHEET, L.H | 1 | ||||
| ? | 424-54-14592 | SHEET, R.H | 1 | ||||
| ? | 423-54-11642 | SHEET, R.H | 1 | ||||
| ? | 423-54-11471 | PLATE | 1 | ||||
| ? | 01435-01020 | BOLT | 3 | ||||
| ? | 424-54-14140 | SEAL | 1 | ||||
| ? | 423-54-11440 | PLATE, L.H | 1 | ||||
| ? | 423-54-11450 | PLATE, R.H | 1 | ||||
| ? | 01435-01020 | BOLT | 6 | ||||
| ? | 424-54-14150 | SEAL | 2 | ||||
| ? | 423-54-A1210 | GRILLE | 1 | ||||
| ? | 01435-01220 | BOLT | 4 | ||||
| ? | 424-54-A1210 | PLATE | 1 | ||||
| ? | 01435-00816 | BOLT | 4 | ||||
| ? | 421-09-12780 | CUSHION, STRIP | 2 | ||||
| ? | 423-54-11931 | COVER - ACCESS DOOR TO ENGINE OIL DIPSTICK | 1 | ||||
| ? | 421-09-12380 | GRIP | 2 | ||||
| ? | 424-54-11641 | PIPE | 2 | ||||
| ? | 01573-22310 | SEAT | 2 | ||||
| ? | 424-54-11260 | SEAT | 2 | ||||
| ? | 419-54-11650 | BAR | 1 | ||||
| ? | 424-54-14320 | SEAT | 2 | ||||
| ? | 01580-00806 | NUT | 8 | ||||
| ? | 01580-01008 | NUT | 11 | ||||
| ? | 01580-01210 | NUT | 6 | ||||
| ? | 08036-40810 | CLIP | 7 |
