Номер на схеме	Каталожный номер	Название	Количество
?	423-54-12871	BOX, CONSOLE	1	F1
?	01010-81225	BOLT	5
?	01643-31232	WASHER	5
?	424-54-14191	PLATE - WITHOUT E.C.S.S	1		a
?	421-S99-1630	PLATE - WITH E.C.S.S	1		b
?	01435-00610	BOLT - WITHOUT E.C.S.S	4		a
?	01435-00814	BOLT - WITH E.C.S.S	4		b
?	425-54-12721	COVER	1
?	01435-00812	BOLT	3
?	423-54-12880	COVER	1
?	01435-00816	BOLT	3
?	425-54-12843	COVER	1
?	01435-00816	BOLT	4
?	09452-06506	CATCHER	1
?	01224-40412	SCREW	2
?	01580-60403	NUT	2
?	01601-20410	WASHER - SPRING	2
?	01641-20405	WASHER	6
?	425-54-12692	PLATE	1
?	01435-01230	BOLT	2
?	425-54-12681	BRACKET	1
?	01435-01225	BOLT	2
?	425-54-12671	COVER	1
?	01220-70616	SCREW	3
?	01642-40608	WASHER	3
?	425-54-12520	PLATE	1
?	01435-01020	BOLT	2
?	425-54-12510	BRACKET	1
?	425-54-12530	SHAFT	1
?	04050-13020	PIN, COTTER	2
?	425-54-12590	STOPPER	2
?	01220-30420	SCREW	2
?	425-54-12570	COVER	1
?	01435-00825	BOLT	2
?	421-54-12175	COVER	1
?	01435-01220	BOLT	6
?	423-54-12910	PLATE	1
?	09415-01610	CAP	1
?	424-54-17520	SHEET, BACK COVER	1
?	424-54-17530	SHEET, FLOOR	1
?	424-54-12830	BOX	1		a
?	425-54-A3010	BOX, L.H. CONSOLE	1	F2	b
?	01435-01225	BOLT	3		a
?	01435-01220	BOLT	3	F2	b
?	424-54-12820	COVER	1
?	01435-01020	BOLT	2
?	01584-01008	NUT	2
?	424-09-12610	COVER	6
?	419-60-15141	PLATE	1		a
?	421-54-13530	PLATE	1	F2	b
?	01435-01220	BOLT	2
?	421-S99-1620	BRACKET - E.C.S.S. OPTION	1
?	7823-43-3000	CONTROLLER, E.C.S.S	1
?	01435-00814	BOLT, BRACKET - E.C.S.S. OPTION	4
?
?		F1 - REFER TO INSTALLATION MANUAL B930023 TO REWORK THE CONSOLE
?		BOX FOR USE WITH E.C.S.S.
?
?		F2 - USED ON MACHINES S/N 4025 AND UP.
?
