| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6150-71-2611) | INJECTION PUMP ASS'Y | 1 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B8 TO A4010-G3B8. | SERIALNO: |
|||||
| ? | THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | SERIALNO: |
|||||
| ? | (ND090100-6710) | • BODY ASS'Y | 1 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B8 AND A4010-C3B8. | SERIALNO: |
|||||
| ? | ND090130-0290 | • • HOLDER,DELIVERY VALVE | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090136-0770 | • • SPRING,DELIVERY | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND949140-2570 | • • O-RING | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090140-1430 | • • VALVE SUB ASS'Y,DELIVERY | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090150-3250 | • • ELEMENT,PUMP | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090160-0060 | • • SLEEVE,CONTROL | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090212-0471 | • • RACK,CONTROL | 1 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090163-0131 | • • SEAT,UPPER | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090164-0250 | • • SPRING,PLUNGER | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090165-0150 | • • SEAT,LOWER | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090170-0230 | • • TAPPET ASS'Y | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0390 | • • SHIM, 1.75MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0400 | • • SHIM, 1.8MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0410 | • • SHIM, 1.85MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0420 | • • SHIM, 1.9MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0430 | • • SHIM, 1.95MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0440 | • • SHIM, 2.0MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0450 | • • SHIM, 2.05MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0460 | • • SHIM, 2.1MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0470 | • • SHIM, 2.15MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0480 | • • SHIM, 2.2MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0490 | • • SHIM, 2.25MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0500 | • • SHIM, 2.3MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0510 | • • SHIM, 2.35MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090438-0520 | • • SHIM, 2.4MM | A/R | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND949013-5880 | • • WASHER | 12 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090139-0020 | • • O-RING | 18 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND949018-1730 | • • WASHER | 6 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090215-0011 | • • SCREW,GUIDE | 1 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090114-0110 | • • BUSHING,CONTROL | 2 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090367-0040 | • • BUSHING,CONTROL | 1 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND090018-0410 | • COVER,CONTROL RACK | 1 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
|||
| ? | ND949018-1550 | • WASHER | 1 | SN: 47990- KIT-FLAG: _- SERIALNO: 47990- |
