| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HOSE, REAR FRAME SUPPLY (SEE PG 02-016) | -29 | 02-016 | ||||
| ? | 9403 252 | UNION, BULK HEAD | 1 | ||||
| ? | 9403 291 | NUT, 7/16NF LOCK | 1 | ||||
| ? | 1129 205 C2 | TUBE, SUPPLY TO REAR FRAME SECONDARY FEEDER | 1 | ||||
| ? | 41 207 D | CLIP, TUBE | 1 | ||||
| ? | 179 805 H1 | CLIP, TUBE | 11 | ||||
| ? | 24 839 R1 | BOLT, 3/8NC X 3/4 | 9 | ||||
| ? | 25 544 R1 | WASHER, 3/8 FLAT | 9 | ||||
| ? | FEEDER, REAR FRAME (SEE PG 02-032) | -29 | 02-032 | ||||
| ? | 25 487 R1 | BOLT, 1/4NC X 1 1/2 | 4 | ||||
| ? | 25 532 R1 | WASHER, 1/4 FLAT | 4 | ||||
| ? | 1129 203 C2 | TUBE, LEFT STEERING CYLINDER ROD | 1 | ||||
| ? | 1129 191 C1 | HOSE, STEERING CYLINDER ROD | 2 | ||||
| ? | 9402 862 | ELBOW, 90° | 4 | ||||
| ? | 1129 211 C2 | TUBE, RIGHT STEERING CYLINDER ROD | 1 | ||||
| ? | 1129 202 C2 | TUBE, BOLSTER REAR | 1 | ||||
| ? | 1129 201 C2 | TUBE, BOLSTER FRONT | 1 | ||||
| ? | 1129 191 C1 | HOSE, BOLSTER REAR | 1 | ||||
| ? | 1129 195 C1 | HOSE, BOLSTER FRONT | 1 | ||||
| ? | 1172 264 C1 | ELBOW, 90° LONG | 2 | ||||
| ? | ELBOW, WELDED ON BOLSTER | 2 | |||||
| ? | 9402 706 | CONNECTOR | 2 | ||||
| ? | 1300 308 H91 | TUBE, BOLSTER FRONT | 1 | ||||
| ? | VY 8 331 | CLIP, TUBE | 3 | ||||
| ? | 24 839 R1 | BOLT, 5/16NC X 3/4 | 3 | ||||
| ? | 25 534 R1 | WASHER, 5/16 FLAT | 3 | ||||
| ? | 1300 309 H91 | TUBE, BOLSTER REAR | 1 |
