| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1136 583 C92 | LEVER ASSY, CONTROL | 1 | F1,F2 | |||
| ? | 1136 584 C1 | • BRACKET, TRANSMISSION CONTROL LEVERS | 1 | ||||
| ? | 1136 588 C91 | • LEVER ASSEMBLY, DIRECTIONAL CONTROL | 1 | F2 | |||
| ? | 1136 586 C1 | • • LEVER WELDMENT | 1 | ||||
| ? | 631 424 C91 | • • BEARING NEEDLE | 2 | ||||
| ? | 1136 587 C91 | • LEVER ASSEMBLY, RANGE, CONTROL | 1 | F2 | |||
| ? | 1136 585 C1 | • • LEVER WELDMENT | 1 | ||||
| ? | 631 424 C91 | • • BEARING NEEDLE | 2 | ||||
| ? | 1131 584 C1 | • WASHER, CUP | 3 | ||||
| ? | 1131 585 C1 | • SHAFT, LEVER MOUNTING | 1 | ||||
| ? | 17 348 R1 | • PIN, 3/16 X 1 3/8 - SLOTTED SPRING | 1 | ||||
| ? | 1133 054 C1 | • LOCK, LEVER | 1 | ||||
| ? | 26 667 R1 | • SCREW, #10-24 X 3/4 | 2 | ||||
| ? | 131 198 | • WASHER, #10 LOCK | 2 | ||||
| ? | 1136 597 C1 | • LEVER, DIRECTIONAL LOCK | 1 | ||||
| ? | 103 342 | • WASHER, 15/32 FLAT | 1 | ||||
| ? | 1136 796 C1 | • RETAINER, LEVER | 1 | ||||
| ? | 1131 775 C1 | • KNOB, CONTROL LEVER | 2 | ||||
| ? | 1268 403 H1 | • KNOB, CONTROL LEVER | 1 | ||||
| ? | 1136 062 C3 | • PRODUCT GRAPHIC, TRANSMISSION CONTROL | 1 | ||||
| ? | |||||||
| ? | F1 - FOR MOUNTING HARDWARE, SEE PG 07-027. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - PART NUMBER IS A NON SERVICE PART | ||||||
| ? | AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? |
