| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1234 692 H91 | BRAKE ASSEMBLY, PARKING | 1 | F1 | |||
| ? | (NSS) | • HOUSING | 1 | ||||
| ? | 1243 251 H1 | • PISTON | 2 | ||||
| ? | 1243 268 H1 | • CAP, SPRING | 2 | ||||
| ? | 1243 284 H91 | • KIT, BRAKE LINING | 2 | ||||
| ? | 1243 269 H1 | • BUTTON, SNAP FASTENER | 4 | ||||
| ? | 1243 270 H1 | • SCREW, FLAT HEAD | 4 | ||||
| ? | 1243 279 H91 | • KIT, SEAL | 2 | ||||
| ? | (NSS) | • • RING, BACKUP | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • RING, BACKUP | 1 | ||||
| ? | 1243 271 H1 | • STUD | 2 | ||||
| ? | 1243 272 H1 | • NUT | 2 | ||||
| ? | 1243 273 H1 | • WASHER | 2 | ||||
| ? | 1243 274 H1 | • PIN, COTTER | 2 | ||||
| ? | 1243 275 H1 | • WASHER | 4 | ||||
| ? | 1243 276 H1 | • WASHER, BELLEVILLE | 16 | ||||
| ? | 1243 277 H1 | • SCREW, BLEEDER | 1 | ||||
| ? | |||||||
| ? | F1 - FOR MOUNTING HARDWARE SEE PG 04-003 | ||||||
| ? |
