| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1268 112 H91 | PUMP ASSEMBLY, WATER | 1 | ||||
| ? | 1235 359 H91 | • PUMP, WATER | 1 | ||||
| ? | 1243 280 H1 | • • MOTOR - 12 VOLT | 1 | ||||
| ? | 1243 281 H1 | • • PLATE, MOTOR | 1 | ||||
| ? | 1243 282 H1 | • • SET, GROMMET - SET OF 4 | 1 | ||||
| ? | 1243 283 H1 | • • SET, BASEPLATE SCREWS - SET OF 2 | 1 | ||||
| ? | 1243 310 H91 | • • HEAD ASSEMBLY, PUMP | 1 | ||||
| ? | 1243 285 H1 | • • • SET, CAM/BEARING SCREWS - SET OF 2 | 1 | ||||
| ? | 1243 287 H1 | • • • SCREW, SET - CAM/BEARING | 1 | ||||
| ? | 1243 288 H1 | • • • CAM/BEARING ASSEMBLY | 1 | ||||
| ? | 1243 289 H1 | • • • COVER, BEARING | 1 | ||||
| ? | 1243 305 H1 | • • • SET, PISTON - INNER AND OUTER | 1 | ||||
| ? | 1243 306 H1 | • • • KIT, DIAPHRAGM | 1 | ||||
| ? | 1243 307 H1 | • • • VALVE ASSEMBLY, CHECK | 1 | ||||
| ? | 1243 308 H1 | • • • HOUSING, PUMP | 1 | ||||
| ? | 1243 309 H1 | • • • SET, PUMP SCREWS - SET OF 6 | 1 | ||||
| ? | 1243 311 H1 | • • KIT, BRUSH | 1 | ||||
| ? | 200 011 | • TERMINAL | 1 | ||||
| ? | 739 070 C1 | • CONNECTOR | 1 | ||||
| ? | 1120 922 C1 | • TERMINAL | 1 | ||||
| ? | |||||||
| ? | NOTE: FOR MOUNTING HARDWARE SEE PG 17-003 |
