| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 119 867 | ELBOW | 2 | ||||
| ? | 391 671 R91 | CLAMP, HOSE | 4 | ||||
| ? | 81 289 | KIT, SERVICE INDICATOR | 1 | ||||
| ? | 81 286 | • NIPPLE, PIPE | 1 | ||||
| ? | 81 287 | • INDICATOR, SERVICE | 1 | ||||
| ? | 1234 294 H91 | TUBE | 1 | ||||
| ? | 24 839 R1 | BOLT | 2 | ||||
| ? | 25 544 R1 | WASHER, FLAT | 2 | ||||
| ? | 1234 235 H91 | BRACKET, AIR CLEANER | 1 | ||||
| ? | 25 493 R1 | BOLT | 4 | ||||
| ? | 25 543 R1 | WASHER, FLAT | 8 | ||||
| ? | 25 520 R1 | NUT, HEX | 4 | ||||
| ? | CLEANER, AIR (SEE PG 12-008) | -29 | 12-008 | ||||
| ? | TURBOCHARGER (SEE ENGINE PARTS MANUAL) | ||||||
| ? | 37 639 A | BAND, AIR CLEANER | 2 |
