| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1233 825 H92 | CYLINDER ASSEMBLY, STEERING | 1 | F1 | |||
| ? | 1233 822 H92 | • TUBE WELDMENT, CYLINDER | 1 | ||||
| ? | 148 398 | • NUT, LOCK | 1 | ||||
| ? | 140 260 H45 | • RING, WEAR | 1 | ||||
| ? | 364 306 R1 | • O-RING | 1 | ||||
| ? | 140 259 H45 | • RING, SEALING | 1 | ||||
| ? | 1250 471 H1 | • PISTON | 1 | ||||
| ? | 364 879 R1 | • O-RING | 1 | ||||
| ? | 28 715 | • RING, RETAINING | 1 | ||||
| ? | 1250 470 H1 | • HEAD, CYLINDER | 1 | ||||
| ? | 140 261 | • SEAL, ROD | 1 | ||||
| ? | 31 032 | • O-RING | 1 | ||||
| ? | 140 258 | • RING, BACK-UP | 1 | ||||
| ? | 1250 478 H1 | • RING, CLAMP | 1 | ||||
| ? | 140 262 | • WIPER, ROD | 1 | ||||
| ? | 1261 576 H91 | • ROD WELDMENT | 1 | ||||
| ? | |||||||
| ? | F1 - FOR MOUNTING HARDWARE SEE PG 10-51 | ||||||
| ? |
