| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1234 977 H93 | VALVE, BRAKE SOLENOID | 1 | ||||
| ? | 1286 886 H91 | • CARTRIDGE, SOLENOID | 1 | ||||
| ? | 1297 887 H1 | • • COIL | 1 | ||||
| ? | (NSS) | • • NUT | 2 | ||||
| ? | (NSS) | • • NUT | 1 | ||||
| ? | (NSS) | • • SPOOL | 1 | ||||
| ? | 1286 888 H1 | • • KIT, SEAL | 1 | ||||
| ? | (NSS) | • • • O-RING | 1 | ||||
| ? | (NSS) | • • • O-RING | 1 | ||||
| ? | (NSS) | • • • RING, BACKUP | 1 | ||||
| ? | (NSS) | • • • O-RING | 1 | ||||
| ? | (NSS) | • • • RING, BACKUP | 1 | ||||
| ? | (NSS) | • BLOCK | 1 |
