| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1267 874 H91 | CONTROL ASSEMBLY, PISTON | 1 | ||||
| ? | (NSS) | • COVER | 1 | ||||
| ? | (NSS) | • O-RING | 2 | F1 | |||
| ? | (NS) | • HOUSING, HYDRAULIC CONTROL | 1 | ||||
| ? | (NSS) | • NUT, HEX | 4 | ||||
| ? | (NSS) | • COLLAR, SPRING | 2 | ||||
| ? | (NSS) | • RING, RETAINING | 2 | ||||
| ? | (NSS) | • COLLAR, SPRING | 4 | ||||
| ? | (NSS) | • SPRING, PRESSURE | 2 | ||||
| ? | (NSS) | • BUSHING, SPACER | 1 | ||||
| ? | (NSS) | • ROD | 1 | ||||
| ? | (NSS) | • PISTON, CONTROL | 1 | ||||
| ? | (NSS) | • RING, SLIDE | 1 | ||||
| ? | (NSS) | • SEAL, LOCK NUT | 1 | F1 | |||
| ? | (NSS) | • COVER | 1 | ||||
| ? | (NSS) | • WASHER, LOCK | 8 | ||||
| ? | (NSS) | • BOLT | 8 | ||||
| ? | |||||||
| ? | F1 - INCLUDED IN THE FOLLOWING: | ||||||
| ? | 134 303 | KIT, SEAL | 1 |
