| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1232 577 H92 | PUMP, STEERING | 1 | F1 | |||
| ? | (NSS) | • HOUSING | 1 | ||||
| ? | (NSS) | • SEAL, SHAFT | 1 | F2 | |||
| ? | 80 336 | • RING, RETAINING | 1 | ||||
| ? | 121 740 | • BEARING | 1 | ||||
| ? | 121 741 | • RING, RETAINING | 1 | ||||
| ? | 1243 609 H1 | • SHAFT | 1 | ||||
| ? | 135 424 | • PIN | 2 | ||||
| ? | 135 422 | • KIT, CARTRIDGE | 1 | ||||
| ? | 135 428 | • • O-RING | 1 | F2 | |||
| ? | 135 427 | • • ROTOR | 1 | ||||
| ? | (NSS) | • • VANE | 12 | ||||
| ? | (NSS) | • • RING | 1 | ||||
| ? | 120 939 | • • O-RING | 1 | ||||
| ? | 121 735 | • SPRING | 1 | F2 | |||
| ? | 121 736 H45 | • PLATE, PRESSURE | 1 | ||||
| ? | (NSS) | • PLUG | 2 | ||||
| ? | 49 163 | • O-RING | 2 | F2 | |||
| ? | 135 136 H1 | • RING, RETAINING | 1 | ||||
| ? | (NSS) | • HOUSING | 1 | ||||
| ? | 1261 074 H1 | • BOLT | 4 | ||||
| ? | 187 325 H1 | • SPRING | 1 | ||||
| ? | 1261 073 H1 | • VALVE, CONTROL | 1 | ||||
| ? | |||||||
| ? | F1 - FOR MOUNTING HARDWARE SEE PG 10-023 | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - INCLUDED IN THE FOLLOWING: | ||||||
| ? | 121 743 H45 | KIT, SEAL | 1 |
