| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1137 360 C1 | SWITCH, ENGINE TEMPERATURE | 1 | ||||
| ? | 1216 162 H1 | SENDING UNIT, ENGINE TEMPERATURE | 1 | ||||
| ? | 158 982 | SWITCH, HYDRAULIC OIL TEMPERATURE | 1 | ||||
| ? | 444 024 | BUSHING, REDUCING | 1 | ||||
| ? | 141 030 | SWITCH, OIL PRESSURE | 1 | ||||
| ? | 105 406 | NIPPLE, PIPE | 1 | ||||
| ? | 150 416 | TEE, PIPE | 1 | ||||
| ? | 677 161 R92 | SENDING UNIT, ENGINE OIL PRESSURE | 1 | ||||
| ? | 120 217 | WASHER, LOCK | 1 | ||||
| ? | 120 614 | NUT, HEX | 1 | ||||
| ? | 1120 331 C1 | SWITCH, ENGINE OIL PRESSURE | 1 | ||||
| ? | 436 732 | SCREW, MACHINE | 5 | ||||
| ? | 138 534 | WASHER, LOCK | 5 | ||||
| ? | 1234 999 H1 | SENDING UNIT, FUEL | 1 | ||||
| ? | 29 362 | GASKET | 1 | ||||
| ? | 1234 978 H1 | SWITCH, BRAKE PRESSURE | 1 | ||||
| ? | 364 839 R1 | • O-RING | 1 |
