Номер на схеме	Каталожный номер	Название	Количество
?	6732-31-3100	KIT, ENGINE CONNECTING ROD	4
?	(NSS)	• ROD, ENGINE CONNECTING	1
?	6732-31-3310	• BOLT, CONNECTING ROD CAP	2
?	6732-31-3130	• BUSHING, CONN ROD	1
?	6732-31-3410	BEARING, CONN. ROD HALF	2
?	6735-31-2070	KIT, ENGINE PISTON - STD	4
?	6736-31-2510	• RING, RETAINING - STD	2
?	6736-31-2030	• SET, PISTON RING - STD	1
?	6736-31-2420	PIN, PISTON	4
?
?		PISTON SERVICE KITS
?		(INCLUDES PISTON & PISTON RINGS)
?	6736-39-2010	KIT, PISTON - 0.50MM OVER	4
?
?		(INCLUDES TOP MIDDLE & OIL RINGS)
?	6736-31-2510	• RING, RETAINING - 0.50MM OVER	2
?	6736-31-2040	• SET, PISTON RING - 0.50MM OVER	1
?	6735-38-2010	KIT, PISTON - 1.00MM OVER	4
?
?		(INCLUDES TOP MIDDLE & OIL RINGS)
?	6736-31-2510	• RING, RETAINING - 1.00MM OVER	2
?	6735-31-2060	• SET, PISTON RING - 1.00MM OVER	1
?
?		UNDERSIZE CONNECTING ROD BEARING HALFS
?	6736-39-3400	BEARING, ROD HALF - 0.25MM UNDER	A/R
?	6736-38-3400	BEARING, ROD HALF - 0.50MM UNDER	A/R
?	6736-37-3400	BEARING, ROD HALF - 0.75MM UNDER	A/R
?	6736-36-3400	BEARING, ROD HALF - 1.00MM UNDER	A/R
