| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6732-21-3810 | GASKET, GEAR HOUSING | 1 | ||||
| ? | 6736-21-3110 | HOUSING, GEAR | 1 | ||||
| ? | 6736-21-3210 | BOLT (8x1.25x50) | 10 | ||||
| ? | 6736-21-3220 | BOLT | 16 | ||||
| ? | 6732-21-3880 | SEAL, RECTANGULAR RING | 1 | ||||
| ? | 6735-21-3180 | HOUSING, TIMING PIN | 1 | ||||
| ? | 6732-21-3870 | • O-RING | 1 | ||||
| ? | 6732-21-3140 | • PIN, TIMING | 1 | ||||
| ? | 6732-21-3150 | • RING, RETAINING | 1 | ||||
| ? | 6732-21-3180 | • HOUSING, TIMING PIN | 1 | ||||
| ? | 6732-21-3160 | SCREW, ROUND HEAD (M5x0.80x17) | 2 | ||||
| ? | 6732-21-3170 | GASKET, GEAR COVER | 1 | ||||
| ? | 1294 346 H91 | COVER, GEAR | 1 | ||||
| ? | 1240 232 H1 | • COVER, GEAR | 1 | ||||
| ? | 6735-21-3510 | • KIT, FRONT SEAL SERVICE | 1 | ||||
| ? | 6736-21-3230 | BOLT (M8x1.25x60) | 1 | ||||
| ? | 6736-21-3810 | RETAINER, BELT | 1 |
