| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1262 557 H91) | TANK & FILTER, HYDRAULIC OIL | -54 | ||||
| ? | 1286 787 H91 | • CAP, FILLER/BREATHER | 1 | ||||
| ? | 1430 480 H1 | • • CAP | 1 | ||||
| ? | 390 427 R1 | • • SCREW, SELF-TAPPING | 6 | ||||
| ? | 1430 481 H1 | • • NECK, FILLER | 1 | ||||
| ? | 1430 482 H1 | • • GASKET | 2 | ||||
| ? | 1430 483 H1 | • • BASKET, STRAINER | 1 | ||||
| ? | 1431 406 H1 | • PLATE, COVER | 1 | ||||
| ? | 85 079 | • PLUG, PIPE | 1 | ||||
| ? | 1286 726 H1 | • GASKET | 1 | ||||
| ? | 25 228 R1 | • BOLT | 6 | ||||
| ? | 25 543 R1 | • WASHER, FLAT | 6 | ||||
| ? | 1282 140 H94 | • TANK, HYDRAULIC OIL | 1 | ||||
| ? | 1110 549 C1 | • GAUGE, SIGHT | 1 | ||||
| ? | 307 915 R1 | • O-RING | 1 | ||||
| ? | • BASE, FILTER (SEE PG 10-128) | -29 | 10-128 | ||||
| ? | 1214 275 H2 | • ELEMENT, HYDRAULIC OIL FILTER | 1 | ||||
| ? | 1282 174 H1 | • STRAINER, SUCTION | 3 |
