| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1431 273 H91 | SPOOL SECTION, VIBRATOR SELECTOR VALVE | 1 | ||||
| ? | 1125 004 C1 | • O-RING | 1 | ||||
| ? | 1431 276 H1 | • END CAP, SPOOL | 1 | ||||
| ? | 1431 277 H1 | • RETAINER | 1 | ||||
| ? | 21 904 | • BOLT | 4 | ||||
| ? | 26 084 R1 | • O-RING | 2 | ||||
| ? | (NSS) | • SPOOL | 1 | ||||
| ? | (NSS) | • BODY | 1 | ||||
| ? | 1280 866 H1 | • RETAINER, SEAL | 1 | ||||
| ? | 26 299 R1 | • O-RING | 1 | ||||
| ? | 1280 863 H1 | • WASHER, FLAT | 2 | ||||
| ? | 1280 865 H1 | • SPACER, SPOOL LIMITER | 1 | ||||
| ? | 1280 864 H1 | • SPRING, SPOOL RETURN | 1 | ||||
| ? | 1280 862 H1 | • BOLT, SHOULDER | 1 | ||||
| ? | 1280 860 H1 | • END CAP, SPOOL | 1 | ||||
| ? | 138 204 | • BOLT | 2 |
