| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1262 582 H91) | BLADE INSTALLATION, LEVELING | -54 | ||||
| ? | • CONTROL, BLADE LIFT VALVE (SEE PG 10-078) | -29 | 10-078 | ||||
| ? | 25 881 R1 | • BOLT | 3 | ||||
| ? | 25 542 R1 | • WASHER, FLAT | 6 | ||||
| ? | 25 519 R1 | • NUT, HEX | 3 | ||||
| ? | 1430 340 H1 | • CABLE, CONTROL | 1 | ||||
| ? | 120 408 | • GROMMET | 1 | ||||
| ? | • KIT, VALVE ADAPTOR (SEE PG 10-082) | -29 | 10-082 | ||||
| ? | 1280 335 H91 | • VALVE, BLADE LIFT | 1 | ||||
| ? | 25 236 R1 | • BOLT | 3 | ||||
| ? | 25 543 R1 | • WASHER, FLAT | 3 | ||||
| ? | 25 520 R1 | • NUT, HEX | 3 | ||||
| ? | 1285 452 H1 | • BRACKET, VALVE MOUNTING | 1 | ||||
| ? | 24 842 R1 | • BOLT | 4 | ||||
| ? | 25 544 R1 | • WASHER, FLAT | 8 | ||||
| ? | 25 522 R1 | • NUT, HEX | 4 |
