| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1262 664 H92 | MOTOR, VIBRATOR | 1 | F1 | |||
| ? | 101 825 | • SEAL, LIP | 1 | ||||
| ? | 101 392 | • RING, RETAINER | 1 | ||||
| ? | 101 818 | • SPACER | 1 | ||||
| ? | 101 396 | • RETAINER, SEAL | 1 | ||||
| ? | 126 222 | • COVER, SHAFT END | 1 | ||||
| ? | 3033 466 R1 | • PLUG | 1 | ||||
| ? | 627 759 C1 | • SEAL, RING | 2 | ||||
| ? | 75 477 | • VALVE, CHECK | 2 | ||||
| ? | 627 727 C1 | • BEARING | 4 | ||||
| ? | 1270 732 H1 | • PLATE, THRUST | 2 | ||||
| ? | 150 558 | • SEAL, POCKET | 12 | ||||
| ? | 1430 501 H1 | • SHAFT & GEAR SET | 1 | ||||
| ? | 99 064 | • SEAL, GASKET | 2 | ||||
| ? | 1430 502 H1 | • HOUSING, GEAR | 1 | ||||
| ? | 126 219 | • PIN, DOWEL | 4 | ||||
| ? | 119 907 | • COVER, PORT END | 1 | ||||
| ? | 3031 159 R1 | • WASHER, PLAIN | 4 | ||||
| ? | 99 065 | • BOLT | 4 | ||||
| ? | |||||||
| ? | F1 - FOR MOUNTING HARDWARE SEE PG 15-009 | ||||||
| ? |
