| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1430 915 H91 | VALVE, FLUSHING | 1 | ||||
| ? | 1430 926 H1 | • PLUG | 1 | ||||
| ? | 134 580 H45 | • O-RING | 1 | F1 | |||
| ? | 1430 927 H1 | • SPRING | 1 | ||||
| ? | 1430 928 H1 | • POPPET, RELIEF VALVE | 1 | ||||
| ? | 1430 929 H1 | • ORIFICE | 1 | ||||
| ? | 430 930 H1 | • RING, RETAINING | 1 | ||||
| ? | 30 994 R1 | • BOLT | 4 | ||||
| ? | 1430 931 H1 | • DISC | 2 | ||||
| ? | 1430 932 H1 | • SPRING | 2 | ||||
| ? | 606 271 C1 | • O-RING | 2 | F1 | |||
| ? | 1430 933 H1 | • PLUG | 2 | ||||
| ? | 1430 934 H1 | • PLUG | 2 | ||||
| ? | 702 788 R1 | • O-RING | 3 | F1 | |||
| ? | 1430 935 H1 | • SHIM | 1 | ||||
| ? | (NSS) | • HOUSING, FLUSHING VALVE | 1 | ||||
| ? | (NSS) | • SPOOL, FLUSHING VALVE | 1 | ||||
| ? | |||||||
| ? | F1 - INCLUDED IN THE FOLLOWING KIT: | ||||||
| ? | 1279 058 H91 | KIT, SEAL | 1 |
