| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1262 560 H92) | ENGINE & MOUNTING | -54 | ||||
| ? | 24 621 R1 | • BOLT | 6 | ||||
| ? | 161 342 | • ADAPTER, FLYWHEEL | 1 | ||||
| ? | 109 968 H45 | • PLATE ASSEMBLY, FLEX | 1 | ||||
| ? | 25 544 R1 | • WASHER, FLAT | 6 | ||||
| ? | 359 783 C1 | • NUT, LOCK | 6 | ||||
| ? | 1282 425 H1 | • PLATE, PUMP MOUNTING | 1 | ||||
| ? | 30 023 R1 | • BOLT | 2 | ||||
| ? | 30 176 R1 | • WASHER, FLAT | 12 | ||||
| ? | 30 022 R1 | • BOLT | 10 | ||||
| ? | FLYWHEEL (SEE PG E2-008) | -29 | E2-008 | ||||
| ? | (1262 545 H91) | TRANSMISSION & CONTROLS, HYDROSTATIC | -54 | ||||
| ? | 1282 426 H2 | • STUD | 4 | ||||
| ? | 25 546 R1 | • WASHER, FLAT | 4 | ||||
| ? | 9412 230 | • NUT, LOCK | 4 | ||||
| ? | • PUMP, PROPULSION DRIVE (SEE PG 10-046) | -29 | 10-046 | ||||
| ? | 27 947 R1 | • O-RING | 1 | ||||
| ? | • PUMP, VIBRATOR (SEE PG 10-064) | -29 | 10-064 | ||||
| ? | 25 546 R1 | • WASHER, FLAT | 2 | ||||
| ? | 24 862 R1 | • BOLT | 2 |
