| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1262 582 H91) | BLADE INSTALLATION, LEVELING | -54 | ||||
| ? | 158 111 | • HOSE | 1 | ||||
| ? | 299 567 | • CLAMP, HOSE | 6 | ||||
| ? | 24 841 R1 | • BOLT | 3 | ||||
| ? | 25 544 R1 | • WASHER, FLAT | 6 | ||||
| ? | 25 522 R1 | • NUT, HEX | 3 | ||||
| ? | 9410 203 | • CONNECTOR | 1 | ||||
| ? | 570 828 R1 | • O-RING | 2 | ||||
| ? | • CYLINDER, BLADE LIFT (SEE PG 10-124) | -29 | 10-124 | ||||
| ? | 1430 330 H1 | • HOSE | 1 | ||||
| ? | 9411 105 | • ELBOW - 45° | 1 | ||||
| ? | 105 516 | • NUT, LOCK | 2 | ||||
| ? | 155 405 | • ELBOW - 45° | 2 | ||||
| ? | 1430 332 H1 | • HOSE | 1 | ||||
| ? | 1430 333 H1 | • HOSE | 1 | ||||
| ? | 21 318 R1 | • BOLT | 1 | ||||
| ? | 25 544 R1 | • WASHER, FLAT | 2 | ||||
| ? | 25 522 R1 | • NUT, HEX | 1 | ||||
| ? | 1430 335 H1 | • HOSE | 1 | ||||
| ? | 1430 334 H1 | • HOSE | 1 | ||||
| ? | 481 352 | • CONNECTOR | 2 | ||||
| ? | 364 885 R1 | • O-RING | 2 | ||||
| ? | 1430 336 H1 | • HOSE - REPLACES ITEM 28, PG 10-007 | 1 | ||||
| ? | 9411 133 | • TEE | 1 | ||||
| ? | 368 269 R1 | • O-RING | 2 | ||||
| ? | • VALVE, BLADE LIFT (SEE PG 10-084) | -29 | 10-084 | ||||
| ? | 9410 205 | • CONNECTOR | 1 | ||||
| ? | 1430 337 H1 | • HOSE | 1 | ||||
| ? | 1430 338 H1 | • HOSE - REPLACES ITEM 20, PG 10-007 | 1 | F1 | |||
| ? | 9410 335 | TEE (SEE PG 10-006) | -29 | 10-006 | |||
| ? | 936 450 R91 | ELBOW - 90° (SEE PG 10-006) | -29 | 10-006 | |||
| ? | 364 885 R1 | O-RING | 1 | ||||
| ? | PUMP, STEERING (SEE PG 10-044) | -29 | 10-044 | ||||
| ? | |||||||
| ? | F1 - USE FOLLOWING CAP TO PLUG OIL COOLER TUBE: | ||||||
| ? | 9403 372 | CAP | 1 |
