| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TANK, HYDRAULIC OIL (SEE PG 10-130) | -29 | 10-130 | ||||
| ? | 71 992 | CONNECTOR, BEADED INSERT | 1 | ||||
| ? | 690 062 C1 | CLAMP, HOSE | 6 | ||||
| ? | 1108 158 C2 | HOSE | 1 | ||||
| ? | 1283 576 H92 | TUBE, TRANSMISSION | 1 | ||||
| ? | 9410 208 | CONNECTOR | 1 | ||||
| ? | 307 915 R1 | O-RING | 1 | ||||
| ? | 1286 855 H1 | HOSE | 1 | ||||
| ? | 1283 577 H1 | TUBE, TRANSMISSION | 1 | ||||
| ? | 391 806 R1 | ELBOW - 90° | 1 | ||||
| ? | 297 247 R1 | O-RING | 1 | ||||
| ? | PUMP, DRUM DRIVE (SEE PG 10-058) | -29 | 10-058 | ||||
| ? | 364 885 R1 | O-RING | 4 | ||||
| ? | 9410 204 | CONNECTOR | 2 | ||||
| ? | 1286 851 H1 | HOSE | 2 | ||||
| ? | PUMP, PROPULSION DRIVE (SEE PG 10-052) | -29 | 10-052 | ||||
| ? | 574 479 R1 | CONNECTOR | 2 | ||||
| ? | 9410 309 | TEE | 2 | ||||
| ? | 732 454 C1 | HOSE | 1 | ||||
| ? | 1283 872 H1 | TEE | 1 | ||||
| ? | 9410 335 | TEE | 1 | ||||
| ? | 9403 404 | REDUCER, TUBE | 1 | ||||
| ? | 9403 530 | NUT, TUBE | 1 | ||||
| ? | 1235 846 H1 | COUPLING, QUICK DISCONNECT | 1 | ||||
| ? | 162 144 | CAP, DUST | 1 | ||||
| ? | 1286 917 H1 | HOSE | 1 | ||||
| ? | 9410 205 | UNION | 1 | ||||
| ? | 368 269 R1 | O-RING | 1 | ||||
| ? | VALVE, PRESSURE REGULATOR (SEE PG 10-102) | -29 | 10-102 | ||||
| ? | 380 633 R1 | UNION | 1 | ||||
| ? | 296 247 R1 | O-RING | 1 | ||||
| ? | FILTER, TRANSMISSION OIL (SEE PG 10-126) | -29 | 10-126 | ||||
| ? | 150 776 C91 | ELBOW - 90° | 1 | ||||
| ? | 1112 013 C1 | HOSE | 1 | ||||
| ? | 30 041 R1 | BOLT | 3 | ||||
| ? | 25 546 R1 | WASHER, FLAT | 3 | ||||
| ? | 1283 437 H92 | BRACKET, FILTER MOUNTING | 1 | ||||
| ? | 24 839 R1 | BOLT | 4 | ||||
| ? | 25 544 R1 | WASHER, FLAT | 4 |
