| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1430 093 H91 | GEARBOX, PLANETARY | 1 | ||||
| ? | 134 442 | • BOLT | 4 | ||||
| ? | 134 440 H45 | • BOLT | 8 | ||||
| ? | 1430 537 H1 | • PLUG, MAGNETIC | 2 | ||||
| ? | 1430 538 H1 | • COVER, INPUT | 1 | ||||
| ? | 134 436 | • WASHER, THRUST | 1 | ||||
| ? | 1430 539 H1 | • WASHER, THRUST | 1 | ||||
| ? | 1430 540 H1 | • GEAR, SUN | 1 | ||||
| ? | 149 432 | • RING, INTERNAL RETAINING | 1 | ||||
| ? | 1430 541 H1 | • SPACER, INPUT | 1 | ||||
| ? | 134 441 | • O-RING | 2 | ||||
| ? | 1430 542 H1 | • GEAR, RING | 1 | ||||
| ? | 1430 543 H1 | • CARRIER, PLANET | 1 | ||||
| ? | 1430 544 H1 | • SHAFT, PLANET | 3 | ||||
| ? | 1430 545 H1 | • PIN, ROLL | 3 | ||||
| ? | 1430 546 H1 | • WASHER, THRUST | 6 | ||||
| ? | 1430 547 H1 | • BEARING, NEEDLE | 96 | ||||
| ? | 134 423 H45 | • SPACER, THRUST | 3 | ||||
| ? | 1430 548 H1 | • GEAR, PLANET | 3 | ||||
| ? | 134 810 | • RING, RETAINING | 1 | ||||
| ? | 1430 549 H1 | • COUPLING | 1 | ||||
| ? | (NSS) | • HOUSING | 1 |
