| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1262 544 H91) | COOLING SYSTEM | -54 | ||||
| ? | • RADIATOR (SEE PG 06-002) | -29 | 06-002 | ||||
| ? | 279 026 R91 | • CLAMP, HOSE | 3 | ||||
| ? | 306 132 C1 | • STRAP, TIE | 2 | ||||
| ? | 1285 968 H1 | • HOSE - UPPER RADIATOR | 1 | ||||
| ? | 176 057 H1 | • NIPPLE, HOSE | 1 | ||||
| ? | 279 025 R91 | • CLAMP, HOSE | 2 | ||||
| ? | 364 357 C1 | • HOSE - 24 IN | 1 | F1 | |||
| ? | 24 840 R1 | • BOLT | 6 | ||||
| ? | 28 422 R1 | • WASHER, FLAT | 12 | ||||
| ? | 25 522 R1 | • NUT, HEX | 6 | ||||
| ? | 1285 914 H1 | • PLATE, MOUNTING | 1 | ||||
| ? | 1234 885 H92 | • TANK, OVERFLOW | 1 | ||||
| ? | 990 017 C1 | • HOSE - 36 IN | 1 | F2 | |||
| ? | 19 400 | • CLAMP | 1 | ||||
| ? | 1281 067 H1 | • HOSE - LOWER RADIATOR | 1 | ||||
| ? | 122 322 R91 | • CLAMP, HOSE | 1 | ||||
| ? | 148 344 | • VALVE, DRAIN | 1 | ||||
| ? | 210 511 R1 | • CLAMP, HOSE | 1 | ||||
| ? | 427 698 C1 | • HOSE | 1 | ||||
| ? | |||||||
| ? | F1 - CUT TO LENGTH FROM 364 357 C1 BULK HOSE | ||||||
| ? | |||||||
| ? | F2 - CUT TO LENGTH FROM 990 017 C1 BULK HOSE | ||||||
| ? |
