Номер на схеме	Каталожный номер	Название	Количество
?	(1430 085 H91)	AXLE, REAR	-54
?	1431 012 H1	• HOUSING, REAR BRAKE OUTER	2
?	1431 013 H1	• HOUSING, REAR BRAKE INNER - R.H	1
?	1431 014 H1	• HOUSING, REAR BRAKE INNER - L.H	1
?	1431 015 H1	• DISC ASSEMBLY	8
?	1431 016 H1	• DISC, INTERMEDIATE	4
?	1431 017 H1	• DISC ASSEMBLY, ACTUATING	2
?	(NSS)	• • DISC, ACTUATING	2
?	1431 018 H1	• • LINK, ACTUATING DISC	2
?	1431 019 H1	• • BALL, ACTUATING DISC	6
?	1431 020 H1	• • SPRING, ACTUATING DISC RETURN	4
?	1431 021 H1	• • PIN, ACTUATING DISC PIVOT	1
?	1431 022 H1	• NUT, JAM	4
?	1431 023 H1	• BOLT	12
?	1430 974 H1	• STUD	4
?	1431 025 H1	• NUT, HEX	4
?	1431 026 H1	• PIN, REAR BRAKE TORQUE	2
?	1431 027 H1	• ROD, BRAKE CONTROL	2
?	1431 028 H1	• PIN, COTTER	2
?	1431 029 H1	• PIN	2
?	1431 030 H1	• SEAL ASSEMBLY	2
