| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EM5220 | FRONT SUSPENSION ASSEMBLY - RH | 1 | ||||
| ? | EM5221 | FRONT SUSPENSION ASSEMBLY - LH | 1 | ||||
| ? | 04071-00190 | • RING, SNAP (1) | 2 | ||||
| ? | 581-50-21450 | • BUSHING (1) | 1 | ||||
| ? | 562-50-31210 | • PLATE, WIPER RETAINER | 1 | ||||
| ? | 01011-81825 | • CAPSCREW - M18 X 2.00 X 125 | 17 | ||||
| ? | 01643-31845 | • FLAT WASHER - M18 | 17 | ||||
| ? | 581-50-21252 | • SEAL (1) | 1 | ||||
| ? | 581-50-11290 | • PACKING (1) | 1 | ||||
| ? | 581-50-11180 | • BUSHING | 2 | ||||
| ? | EK5288 | • FLANGE | 1 | ||||
| ? | 07001-05330 | • RING, BACKUP (1) | 1 | ||||
| ? | 07000-15330 | • O-RING (1) | 1 | ||||
| ? | 07043-00108 | • PLUG | 1 | ||||
| ? | 566-50-11350 | • PACKING (1) | 3 | ||||
| ? | 566-50-21260 | • VALVE | 1 | ||||
| ? | PC1460 | • BUFFER RING | 1 | ||||
| ? | 581-50-11520 | • BUSHING (1) | 1 | ||||
| ? | 562-50-31220 | • RETAINER | 1 | ||||
| ? | 562-50-A1110 | • CYLINDER - RH | 1 | ||||
| ? | 562-50-A1100 | • CYLINDER - LH | 1 | ||||
| ? | 566-50-41310 | • PLATE (1) | 1 | ||||
| ? | 581-50-11511 | • RING, WEAR | 1 | ||||
| ? | EJ4999 | • ROD ASSEMBLY | 1 | ||||
| ? | EK5278 | • • ROD | 1 | ||||
| ? | 562-50-31410 | • • STOPPER | 1 | ||||
| ? | 561-86-67700 | • VALVE ASSEMBLY | 1 | ||||
| ? | 561-86-67710 | • • VALVE | 1 | ||||
| ? | 281-50-11721 | • • CORE, VALVE | 1 | ||||
| ? | 566-50-11301 | • VALVE (1) | 1 | ||||
| ? | 07000-01006 | • • O-RING | 1 | ||||
| ? | 281-50-11721 | • • CORE, VALVE | 1 | ||||
| ? | 566-50-11320 | • • VALVE | 1 | ||||
| ? | 566-50-11340 | • • CAP | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | 7861-93-1620 | SENSOR, PRESSURE | 1 | ||||
| ? | VJ3911 | OIL, SUSPENSION (5 GALLON CAN) | 4 | ||||
| ? | AK3761 | ADDITIVE, OIL (5 GALLON CAN) | 1 | ||||
| ? | NOTE: (1) INCLUDED IN AK4206 FRONT SUSPENSION REBUILD KIT. |
