| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB0262 | FITTING, 90 DEG ELBOW | 1 | ||||
| ? | VW7990 | CAP, PROTECTIVE | 3 | ||||
| ? | TA4410 | INJECTOR (3 PIECE) (1) | 1 | ||||
| ? | WB0252 | FITTING, 90 DEGREE ELBOW | 3 | ||||
| ? | C5770 | PLUG, PIPE | 1 | ||||
| ? | HA5552 | HOSE | 1 | ||||
| ? | HA6834 | HOSE | 1 | ||||
| ? | MM0610 | CAPSCREW - M10 X 1.50 X 50 | 2 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 6 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 2 | ||||
| ? | WA6192 | FITTING, 90 DEGREE ELBOW | 2 | ||||
| ? | WB0454 | FITTING, STRAIGHT | 1 | ||||
| ? | 01597-01009 | NUT - M10 X 1.50 | 2 | ||||
| ? | HA5842 | HOSE | 1 | ||||
| ? | 01643-31032 | FLAT WASHER - M10 | 2 | ||||
| ? | WB1300 | CLAMP, CUSHION - 5/8" | 5 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 2 | ||||
| ? | MM0693 | LOCKNUT - M10 X 1.50 | 2 | ||||
| ? | 07283-34346 | CLIP, PIPE | 1 | ||||
| ? | 561-61-63660 | PLATE | 1 | ||||
| ? | NOTE: (1) FOR SINGLE INJECTOR, ORDER VS1947 | ||||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
