| Наименование | Страница | Код страницы |
|---|---|---|
| HOIST PILOT VALVE ASSEMBLY (PB6922) | 570 | 40064 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HA6354 | HOSE | 1 | ||||
| ? | HA6419 | HOSE | 1 | ||||
| ? | HA6370 | HOSE | 1 | ||||
| ? | PC1372 | MANIFOLD, HOIST PILOT | 1 | ||||
| ? | WB0139 | FITTING, 90 DEGREE ELBOW | 4 | ||||
| ? | WB0102 | FITTING, STRAIGHT | 4 | ||||
| ? | PB9501 | CABLE | 1 | ||||
| ? | HA8101 | HOSE | 1 | ||||
| ? | PB6895 | CONNECTION KIT | 1 | ||||
| ? | HA5992 | HOSE | 1 | ||||
| ? | MM0047 | CAPSCREW - M10 X 1.50 X 30 | 4 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 4 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 4 | ||||
| ? | WB1285 | FITTING, STRAIGHT | 1 | ||||
| ? | PC1587 | VALVE, SOLENOID | 1 | ||||
| ? | PB6922 | VALVE, HOIST PILOT (SEE INDEX) | 1 | 40064 | |||
| ? | WB0162 | FITTING, TEE | 1 |
