| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6150-71-1122) | INJECTION PUMP A. | 1 | SN: 10001-11478 |
|||
| ? | (□6150-71-1121) | INJECTION PUMP A. | 1 | SN: 10001-11478 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482. | ||||||
| ? | THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | (ND090100-5500) | • BODY ASS'Y | 1 | SN: 10001-11478 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453 AND 0454. | ||||||
| ? | ND090130-0240 | • • HOLDER,DELIVERY VALVE | 6 | SN: 10001-11478 |
|||
| ? | ND090136-0660 | • • SPRING,DELIVERY VALVE | 6 | SN: 10001-11478 |
|||
| ? | ND949140-2570 | • • O-RING | 6 | SN: 10001-11478 |
|||
| ? | ND090140-1430 | • • VALVE SUB ASS'Y,DELIVERY | 6 | SN: 10001-11478 |
|||
| ? | ND090150-3250 | • • ELEMENT | 6 | SN: 10001-11478 |
|||
| ? | ND090160-0060 | • • SLEEVE,CONTROL | 6 | SN: 10001-11478 |
|||
| ? | ND090212-0470 | • • RACK,CONTROL | 1 | SN: 10001-11478 |
|||
| ? | ND090163-0131 | • • SEAT,SPRING¤ UPPER | 6 | SN: 10001-11478 |
|||
| ? | ND090164-0211 | • • SPRING,PLUNGER | 6 | SN: 10001-11478 |
|||
| ? | ND090165-0150 | • • SEAT,SPRING¤ LOWER | 6 | SN: 10001-11478 |
|||
| ? | ND090170-0230 | • • TAPPET ASS'Y | 6 | SN: 10001-11478 |
|||
| ? | ND090438-0860 | • • SHIM¤ 1.35MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0620 | • • SHIM¤ 1.4MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0870 | • • SHIM¤ 1.45MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0630 | • • SHIM¤ 1.5MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0880 | • • SHIM¤ 1.55MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0890 | • • SHIM¤ 1.6MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0900 | • • SHIM¤ 1.65MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0910 | • • SHIM¤ 1.7MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0390 | • • SHIM¤ 1.75MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0400 | • • SHIM¤ 1.8MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0410 | • • SHIM¤ 1.85MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0420 | • • SHIM¤ 1.9MM | A/R | SN: 10001-11478 |
|||
| ? | ND090438-0430 | • • SHIM¤ 1.95MM | A/R | SN: 10001-11478 |
|||
| ? | ND949013-5880 | • • WASHER | 12 | SN: 10001-11478 |
|||
| ? | ND090139-0020 | • • O-RING | 18 | SN: 10001-11478 |
|||
| ? | ND949018-1730 | • • WASHER | 6 | SN: 10001-11478 |
|||
| ? | ND090215-0021 | • • SCREW | 1 | SN: 10001-11478 |
|||
| ? | ND090114-0110 | • • BUSHING | 2 | SN: 10001-11478 |
|||
| ? | ND090367-0040 | • • BUSHING | 1 | SN: 10001-11478 |
|||
| ? | ND090018-0410 | • COVER | 1 | SN: 10001-11478 |
|||
| ? | ND949018-1550 | • WASHER | 1 | SN: 10001-11478 |
