| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6150-71-1220 | INJECTION PUMP A. | 1 | SN: 11479- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453A TO 0482A. | ||||||
| ? | THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | ND090100-7580 | • BODY ASS'Y | 1 | SN: 11479- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453A AND 0454A. | ||||||
| ? | ND190110-4110 | • • HOUSING | 1 | SN: 11479- |
|||
| ? | ND949043-0010 | • • • STUD | 3 | SN: 11479- |
|||
| ? | ND090191-1180 | • • CAMSHAFT | 1 | SN: 11479- |
|||
| ? | ND090193-0020 | • • RING | 1 | SN: 11479- |
|||
| ? | ND090194-0010 | • • SHIM¤ 0.10MM | A/R | SN: 11479- |
|||
| ? | ND090194-0020 | • • SHIM¤ 0.12MM | A/R | SN: 11479- |
|||
| ? | ND090194-0030 | • • SHIM¤ 0.14MM | A/R | SN: 11479- |
|||
| ? | ND090194-0040 | • • SHIM¤ 0.16MM | A/R | SN: 11479- |
|||
| ? | ND090194-0050 | • • SHIM¤ 0.18MM | A/R | SN: 11479- |
|||
| ? | ND090194-0110 | • • SHIM¤ 0.3MM | A/R | SN: 11479- |
|||
| ? | ND090194-0060 | • • SHIM¤ 0.50MM | A/R | SN: 11479- |
|||
| ? | ND090194-0140 | • • SHIM¤ 1.0MM | A/R | SN: 11479- |
|||
| ? | ND090194-0150 | • • SHIM¤ 1.5MM | A/R | SN: 11479- |
|||
| ? | ND090201-0310 | • • COVER | 1 | SN: 11479- |
|||
| ? | ND949140-1550 | • • O-RING | 1 | SN: 11479- |
|||
| ? | ND949150-1620 | • • SEAL,OIL | 1 | SN: 11479- |
|||
| ? | ND090270-0691 | • • COVER ASS'Y | 1 | SN: 11479- |
|||
| ? | ND090275-0083 | • • • COVER | 1 | SN: 11479- |
|||
| ? | ND090272-0220 | • • • GASKET | 1 | SN: 11479- |
|||
| ? | ND090243-0030 | • • • WASHER | 2 | SN: 11479- |
|||
| ? | ND090276-0030 | • • • SCREW | 2 | SN: 11479- |
|||
| ? | ND949047-1360 | • • BOLT | 4 | SN: 11479- |
|||
| ? | ND949101-0120 | • • BEARING | 1 | SN: 11479- |
|||
| ? | ND949140-0380 | • • O-RING | 1 | SN: 11479- |
|||
| ? | ND090310-0080 | • • VALVE ASS'Y,OVER FLOW | 1 | SN: 11479- |
|||
| ? | ND090361-0040 | • • BEARING,CENTER | 1 | SN: 11479- |
|||
| ? | ND91050-05351 | • • SCREW | 2 | SN: 11479- |
|||
| ? | ND949018-1030 | • • WASHER | 2 | SN: 11479- |
|||
| ? | ND949180-0310 | • • SCREW | 2 | SN: 11479- |
|||
| ? | ND090222-0070 | • • WASHER | 6 | SN: 11479- |
|||
| ? | ND090193-0050 | • • RING | 1 | SN: 11479- |
|||
| ? | ND090194-0070 | • • PLATE¤ 0.1MM | A/R | SN: 11479- |
|||
| ? | ND090194-0340 | • • PLATE¤ 0.12MM | A/R | SN: 11479- |
|||
| ? | ND090194-0350 | • • PLATE¤ 0.14MM | A/R | SN: 11479- |
|||
| ? | ND090194-0080 | • • PLATE¤ 0.15MM | A/R | SN: 11479- |
|||
| ? | ND090194-0360 | • • PLATE¤ 0.18MM | A/R | SN: 11479- |
|||
| ? | ND090194-0090 | • • PLATE¤ 0.3MM | A/R | SN: 11479- |
|||
| ? | ND090194-0100 | • • PLATE¤ 0.5MM | A/R | SN: 11479- |
|||
| ? | ND949101-0071 | • • BEARING | 1 | SN: 11479- |
|||
| ? | ND090012-0180 | • NUT | 1 | SN: 11479- |
|||
| ? | ND90258-08001 | • WASHER,SPRING | 1 | SN: 11479- |
|||
| ? | ND949130-0210 | • KEY | 1 | SN: 11479- |
