| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6150-71-1122 | INJECTION PUMP A. | 1 | SN: 10001-11478 |
|||
| ? | □6150-71-1121 | INJECTION PUMP A. | 1 | SN: 10001-11478 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482. | ||||||
| ? | THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | ND090100-5500 | • BODY ASS'Y | 1 | SN: 10001-11478 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453 AND 0454. | ||||||
| ? | ND090110-3290 | • • HOUSING | 1 | SN: 10001-11478 |
|||
| ? | ND949043-0010 | • • • STUD | 3 | SN: 10001-11478 |
|||
| ? | ND949140-0970 | • • O-RING | 1 | SN: 10001-11478 |
|||
| ? | ND090191-0920 | • • CAMSHAFT | 1 | SN: 10001-11478 |
|||
| ? | ND949101-0140 | • • BEARING,ROLLER | 1 | SN: 10001-11478 |
|||
| ? | ND090193-0050 | • • RING,ADJUST | 1 | SN: 10001-11478 |
|||
| ? | ND090194-0070 | • • PLATE¤ 0.1MM | A/R | SN: 10001-11478 |
|||
| ? | ND090194-0340 | • • PLATE¤ 0.12MM | A/R | SN: 10001-11478 |
|||
| ? | ND090194-0350 | • • PLATE¤ 0.14MM | A/R | SN: 10001-11478 |
|||
| ? | ND090194-0080 | • • PLATE¤ 0.15MM | A/R | SN: 10001-11478 |
|||
| ? | ND090194-0360 | • • PLATE¤ 0.18MM | A/R | SN: 10001-11478 |
|||
| ? | ND090194-0090 | • • PLATE¤ 0.3MM | A/R | SN: 10001-11478 |
|||
| ? | ND090194-0100 | • • PLATE¤ 0.5MM | A/R | SN: 10001-11478 |
|||
| ? | ND949150-1420 | • • SEAL,OIL | 1 | SN: 10001-11478 |
|||
| ? | ND090201-0430 | • • COVER,BEARING | 1 | SN: 10001-11478 |
|||
| ? | ND949047-1380 | • • BOLT | 4 | SN: 10001-11478 |
|||
| ? | ND090433-0020 | • • RETAINER,BEARING | 1 | SN: 10001-11478 |
|||
| ? | ND090361-0100 | • • BEARING,CENTER | 1 | SN: 10001-11478 |
|||
| ? | ND090248-0010 | • • WASHER | 2 | SN: 10001-11478 |
|||
| ? | ND090317-0140 | • • PLUG | 1 | SN: 10001-11478 |
|||
| ? | ND090193-0060 | • • RING,ADJUST | 1 | SN: 10001-11478 |
|||
| ? | ND090118-0250 | • • NEEDLE,TIMING | 1 | SN: 10001-11478 |
|||
| ? | ND090222-0070 | • • WASHER | 4 | SN: 10001-11478 |
|||
| ? | ND949180-0310 | • • SCREW | 2 | SN: 10001-11478 |
|||
| ? | ND949140-0380 | • • O-RING | 1 | SN: 10001-11478 |
|||
| ? | ND949101-0130 | • • BEARING,ROLLER | 1 | SN: 10001-11478 |
|||
| ? | ND090194-0300 | • • PLATE¤ 0.1MM | A/R | SN: 10001-11478 |
|||
| ? | ND090194-0310 | • • PLATE¤ 0.16MM | A/R | SN: 10001-11478 |
|||
| ? | ND090194-0320 | • • PLATE¤ 0.3MM | A/R | SN: 10001-11478 |
|||
| ? | ND090194-0330 | • • PLATE¤ 0.5MM | A/R | SN: 10001-11478 |
|||
| ? | ND949047-0620 | • • BOLT | 2 | SN: 10001-11478 |
|||
| ? | ND949018-0350 | • • WASHER | 1 | SN: 10001-11478 |
|||
| ? | ND090012-0140 | • NUT | 1 | SN: 10001-11478 |
|||
| ? | ND90801-40280 | • O-RING | 1 | SN: 10001-11478 |
|||
| ? | ND949014-0070 | • WASHER | 1 | SN: 10001-11478 |
|||
| ? | ND090222-0070 | • WASHER | 2 | SN: 10001-11478 |
|||
| ? | ND090310-0080 | • VALVE ASS'Y,OVER FLOW | 1 | SN: 10001-11478 |
|||
| ? | ND90458-05750 | • KEY | 1 | SN: 10001-11478 |
