| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 426-93-21570 | Plate Assembly | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09653-A0641 | • Plate, Warning, High Temperature | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09653-A0641 | • Plate, Warning, High Temperature | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09808-A1201 | • Plate, Warning, Battery Cables | 2 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09162-C0641 | • Plate, Danger, Keep Off | 2 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09161-C0641 | • Plate, Warning, Articulation Lock | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09667-A0880 | • Plate, Caution, Rotating Object | 2 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 423-93-41172 | Plate Assembly | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | • Plate, Remote Grease, Cylinder | 1 | SN: 66058- KIT-FLAG: _- SCC: C1 SERIALNO: 66058- |
||||
| ? | • Plate, Remote Grease, Rear Axle | 1 | SN: 66058- KIT-FLAG: _- SCC: C1 SERIALNO: 66058- |
||||
| ? | • Plate, Radiator Drain | 1 | SN: 66058- KIT-FLAG: _- SCC: C1 SERIALNO: 66058- |
||||
| ? | • Plate, Engine Oil Drain | 1 | SN: 66058- KIT-FLAG: _- SCC: C1 SERIALNO: 66058- |
||||
| ? | • Plate, Parking Brake Emergency Release Switch | 1 | SN: 66058- KIT-FLAG: _- SCC: C1 SERIALNO: 66058- |
||||
| ? | • Plate, Parking Brake Emergency Release Method | 1 | SN: 66058- KIT-FLAG: _- SCC: C1 SERIALNO: 66058- |
||||
| ? | 09805-C0881 | • Plate, Caution, Do not Get On | 2 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 423-93-41162 | Oil Chart | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 423-93-41110 | Plate, Mark, WA380, L.H. | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 423-93-41120 | Plate, Mark, WA380. R.H. | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 423-93-41130 | Plate | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 423-93-41140 | Plate | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09690-P0710 | Plate, Komatsu Logo | 2 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09806-C0883 | Plate, Danger, Keep Away from Machine | 2 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09807-C0883 | Plate, Danger, Keep Out under Work Equipment | 2 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09960-01601 | Mark, Lift Point and Tie Down Point Marks | 4 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09669-0000E | Plate, Symbol, Fuel Filler | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09659-A057B | Plate, Warning, Explosion Hazard, PPC | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09659-A057B | Plate, Warning, Explosion Hazard, Brake | 2 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09659-A057B | Plate, Warning, Explosion Hazard, ECSS | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | (09602-10001) | Plate, Name (Limited Supply) | 1 | SN: 66058- KIT-FLAG: _- SCC: C2 SERIALNO: 66058- |
|||
| ? | 04418-13060 | Screw | 4 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 09667-A0481 | Plate, Caution, Rotating Object | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 20Y-00-41530 | Plate, Symbol, Ecot3 | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 20Y-00-41340 | Plate, Pre Filter Caution | 1 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
|||
| ? | 14X-98-35181 | Plate, Reflector | 2 | SN: 66058- KIT-FLAG: _- SCC: SERIALNO: 66058- |
