| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (200120061) | GEAR SHAFT, ASSY | 1 | TRSN: 101- |
|||
| ? | CA0139348 | • SPRING | 1 | TRSN: 101- |
|||
| ? | CA0139347 | • LOCK-SPRING COVER | 1 | TRSN: 101- |
|||
| ? | CA0025021 | • LOCKRING | 1 | TRSN: 101- |
|||
| ? | CA0140141 | • CLUTCH PISTON | 1 | TRSN: 101- |
|||
| ? | CA0138372 | • SEAL RING | 1 | TRSN: 101- |
|||
| ? | CA0028015 | • NEEDLE BEARING BUSH | 2 | TRSN: 101- |
|||
| ? | CA0137825 | • SEAL RING | 1 | TRSN: 101- |
|||
| ? | CA0138369 | • GEAR | 1 | TRSN: 101- |
|||
| ? | CA0133379 | • SPACER | 1 | TRSN: 101- |
|||
| ? | CA0028350 | • BUSH | 2 | TRSN: 101- |
|||
| ? | CA0138364 | • SEAL RING | 2 | TRSN: 101- |
|||
| ? | CA0138398 | • COVER | 1 | TRSN: 101- |
|||
| ? | CA0020852 | • BOLT | 4 | TRSN: 101- |
|||
| ? | CA0024799 | • SNAP RING | 1 | TRSN: 101- |
|||
| ? | CA0079175 | • THRUST WASHER | 1 | TRSN: 101- |
|||
| ? | CA0026190 | • BEARING | 1 | TRSN: 101- |
|||
| ? | CA0106866 | • SHIM 0.1 MM | A/R | TRSN: 101- |
A | ||
| ? | CA0106867 | • SHIM 0.3 MM | A/R | TRSN: 101- |
B | ||
| ? | CA0106868 | • SHIM 0.5 MM | A/R | TRSN: 101- |
C | ||
| ? | CA0140117 | • BELLEVILLE WASHER | 1 | TRSN: 101- |
|||
| ? | CA0140116 | • BELLEVILLE WASHER | 2 | TRSN: 101- |
|||
| ? | SEE FIG. 3245 | 3245 |
