| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (844020280) | CONTROL VALVE,ASSY | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | (844020338) | CONTROL VALVE,ASSY | 1 | SN: 150EF80048- |
B | ||
| ? | (844200507) | • BLOCK, BUCKET CONTROL ASSY | 1 | SN: 150EF80001- |
|||
| ? | ☆ | • • HOUSING KIT | 1 | SN: 150EF80001- |
|||
| ? | 844200503 | • • COMPESATOR KIT | 1 | SN: 150EF80001- |
|||
| ? | 844200416 | • • VALVE KIT | 2 | SN: 150EF80001- |
|||
| ? | 844200459 | • • SOLENOпD KIT | 2 | SN: 150EF80001- |
|||
| ? | 844200422 | • • SECONDARY VALVE | 2 | SN: 150EF80001- |
|||
| ? | 844200174 | • • • GASKET KIT | 1 | SN: 150EF80001- |
|||
| ? | 844200423 | • • LOCKING COVER KIT (ORANGE) | 1 | SN: 150EF80001- |
|||
| ? | 844200424 | • • LOCKING COVER KIT (BLUE) | 1 | SN: 150EF80001- |
|||
| ? | 844200504 | • • GASKET KIT | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | 844200699 | • • GASKET KIT | 1 | SN: 150EF80048- |
B | ||
| ? | ☆ | • • • O-RING | 2 | SN: 150EF80001- |
|||
| ? | ☆ | • • • O-RING | 2 | SN: 150EF80001- |
|||
| ? | 844200413 | • • • GASKET KIT | 1 | SN: 150EF80001- |
|||
| ? | ☆ | • • • O-RING | 2 | SN: 150EF80001- |
|||
| ? | ☆ | • • • O-RING | 1 | SN: 150EF80001- |
