| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (844020280) | SHOVEL CONTROL VALVE, ASSY | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | (844020338) | SHOVEL CONTROL VALVE, ASSY | 1 | SN: 150EF80048- |
B | ||
| ? | (844200463) | • FLOATING BLOCK, SHOVEL LIFTING, ASSY | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | (844200711) | • FLOATING BLOCK, SHOVEL LIFTING, ASSY | 1 | SN: 150EF80048- |
B | ||
| ? | ☆ | • • HOUSING KIT | 1 | SN: 150EF80001- |
|||
| ? | 844200503 | • • COMPESATOR KIT | 1 | SN: 150EF80001- |
|||
| ? | 844200416 | • • VALVE KIT | 2 | SN: 150EF80001- |
|||
| ? | 844200615 | • • OPERATION KIT | 1 | SN: 150EF80001- |
|||
| ? | 844200427 | • • • BELLOWS KIT | 1 | SN: 150EF80001- |
|||
| ? | 844200417 | • • COVER KIT | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | 844200698 | • • COVER KIT | 1 | SN: 150EF80048- |
B | ||
| ? | 844200504 | • • GASKET KIT | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | 844200699 | • • GASKET KIT | 1 | SN: 150EF80048- |
B | ||
| ? | 844200509 | • • • GASKET KIT | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | 844200632 | • • • GASKET KIT | 1 | SN: 150EF80048- |
B | ||
| ? | ☆ | • • • • OIL SEAL | 1 | SN: 150EF80001- |
A | ||
| ? | ☆ | • • • • OIL SEAL | 2 | SN: 150EF80048- |
B | ||
| ? | ☆ | • • • • O-RING | 2 | SN: 150EF80001-150EF80047 |
|||
| ? | ☆ | • • • • O-RING | 1 | SN: 150EF80001- |
|||
| ? | 844200413 | • • • GASKET KIT | 1 | SN: 150EF80001- |
|||
| ? | ☆ | • • • O-RING | 2 | SN: 150EF80001- |
|||
| ? | ☆ | • • • O-RING | 1 | SN: 150EF80001- |
