| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 844020280 | SHOVEL CONTROL VALVE,ASSY | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | 844020338 | SHOVEL CONTROL VALVE,ASSY | 1 | SN: 150EF80048- |
B | ||
| ? | 844200493 | • INLET ELEMENT, ASSY | 1 | SN: 150EF80001- |
|||
| ? | 844200463 | • BLOCK, SHOVEL LIFTING, ASSY | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | 844200711 | • BLOCK, SHOVEL LIFTING, ASSY | 1 | SN: 150EF80048- |
B | ||
| ? | 844200495 | • BLOCK, SHOVEL DUMPING, ASSY | 1 | SN: 150EF80001-150EF80047 |
A | ||
| ? | 844200709 | • BLOCK, SHOVEL DUMPING, ASSY | 1 | SN: 150EF80048- |
B | ||
| ? | 844200507 | • BLOCK, BUCKET CONTROL ASSY | 1 | SN: 150EF80001- |
|||
| ? | 844200494 | • OUTLET SECTION, ASSY | 1 | SN: 150EF80001- |
|||
| ? | 844200413 | • • GASKET KIT | 1 | SN: 150EF80001- |
|||
| ? | 844200411 | • • PLUG | 1 | SN: 150EF80001- |
|||
| ? | 844200465 | • TIE RODS KIT | 1 | SN: 150EF80001- |
|||
| ? | SEE FIG. 6270 | 6270 | |||||
| ? | SEE FIG. 6275 | 6275 | |||||
| ? | SEE FIG. 6280 | 6280 | |||||
| ? | SEE FIG. 6265 | 6265 |
