| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (880011082) | AIR BLENDING SYSTEM, ASSY | 1 | SN: 150EF80001- |
|||
| ? | (880011083) | • MOTOR AIR BLENDING SYSTEM, KIT | 1 | SN: 150EF80001- |
|||
| ? | 312649115 | • • FILTER | 1 | SN: 150EF80001- |
|||
| ? | 312649116 | • • FILTER SUPPORT | 1 | SN: 150EF80001- |
|||
| ? | 801880206 | • • SELF-LOCKING NUT | 2 | SN: 150EF80001- |
|||
| ? | 802170000 | • • WASHER | 2 | SN: 150EF80001- |
|||
| ? | 312649120 | • • HOSE | 1 | SN: 150EF80001- |
|||
| ? | 312649117 | • • AIR PRESSURE SWITCH | 1 | SN: 150EF80001- |
|||
| ? | 312649059 | • • FLANGE | 1 | SN: 150EF80001- |
|||
| ? | 801105523 | • • SCREW | 1 | SN: 150EF80001- |
|||
| ? | 880011075 | • • SPRING WASHER | 1 | SN: 150EF80001- |
|||
| ? | 312649119 | • • HOSE | 1 | SN: 150EF80001- |
|||
| ? | 312649607 | • • O-RING | 1 | SN: 150EF80001- |
|||
| ? | 312649108 | • • COMPRESSOR | 1 | SN: 150EF80001- |
|||
| ? | 801015561 | • • BOLT | 1 | SN: 150EF80001- |
|||
| ? | 801015111 | • • BOLT | 1 | SN: 150EF80001- |
|||
| ? | 802170002 | • • WASHER | 6 | SN: 150EF80001- |
|||
| ? | 312649066 | • • SUPPORT | 1 | SN: 150EF80001- |
|||
| ? | 312649091 | • • PROTECTION | 1 | SN: 150EF80001- |
|||
| ? | 801015090 | • • BOLT | 4 | SN: 150EF80001- |
|||
| ? | 802170001 | • • WASHER | 4 | SN: 150EF80001- |
|||
| ? | 801703008 | • • NUT | 2 | SN: 150EF80001- |
|||
| ? | 802150508 | • • SPRING WASHER | 2 | SN: 150EF80001- |
|||
| ? | 312640609 | • • SPACER | 1 | SN: 150EF80001- |
|||
| ? | 801880001 | • • SELF-LOCKING NUT | 1 | SN: 150EF80001- |
|||
| ? | 312649067 | • • BRACKET | 1 | SN: 150EF80001- |
|||
| ? | 801015111 | • • BOLT | 2 | SN: 150EF80001- |
|||
| ? | 801015110 | • • BOLT | 1 | SN: 150EF80001- |
|||
| ? | 312649109 | • • COMPRESSOR SUPPORT | 1 | SN: 150EF80001- |
|||
| ? | 801015087 | • • BOLT | 1 | SN: 150EF80001- |
|||
| ? | SEE FIG. 0601 | 0601 | |||||
| ? | SEE FIG. 5900 | 5900 | |||||
| ? | SEE FIG. 5930 | 5930 |
