| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 885270291 | FRONT DASHBOARD, ASSY. | 1 | SN: 8905908-; 8901442-8917801 |
A | ||
| ? | 885270510 | FRONT DASHBOARD, ASSY. | 1 | SN: 8917808- |
B | ||
| ? | 885141051 | • LAMP HOLDER | 14 | SN: 8905908-; 8901442- |
|||
| ? | 885140026 | • BULB | 14 | SN: 8901442- |
|||
| ? | 885141166 | • GLASS, OIL ENGINE PRESSURE | 1 | SN: 8901442- |
|||
| ? | 885141167 | • GLASS, OIL TEMPERATURE | 1 | SN: 8901442- |
|||
| ? | 885141118 | • GLASS, AIR FILTER CLOGGING | 1 | SN: 8901442- |
|||
| ? | 885141122 | • GLASS, ENGINE COOLANT THERMOMETER | 1 | SN: 8901442- |
|||
| ? | 885141120 | • GLASS, OIL ENGINE PRESSURE | 1 | SN: 8901442- |
|||
| ? | 885141117 | • GLASS, DIRECTION INDICATOR | 1 | SN: 8901442- |
|||
| ? | 885141119 | • GLASS, GENERATOR | 1 | SN: 8901442- |
|||
| ? | 885141111 | • GLASS, FUEL LEVEL INDICATOR | 1 | SN: 8901442- |
|||
| ? | 885141116 | • GLASS, HAND BRAKE | 1 | SN: 8901442- |
|||
| ? | 885141127 | • GLASS, 4WD | 1 | SN: 8901442- |
|||
| ? | 885141114 | • GLASS, SAIL LIGHT | 1 | SN: 8901442- |
|||
| ? | 885141115 | • GLASS, HEADLIGHT | 1 | SN: 8901442- |
|||
| ? | 885141164 | • GLASS, DIFFERENTIAL LOCKING | 1 | SN: 8901442- |
|||
| ? | 885081102 | • SWITCH | 1 | SN: 8901442- |
|||
| ? | 885141072 | • BULB | 6 | SN: 8901442- |
|||
| ? | 885141165 | • PUSHBUTTON | 1 | SN: 8901442- |
|||
| ? | 885141153 | • GLASS, REDUCTOR DISCONNECTING | 1 | SN: 8901442- |
|||
| ? | 801350042 | • SCREW | 7 | SN: 8901442- |
|||
| ? | 311305753 | • FRONT INSTRUMENT BOARD | 1 | SN: 8901442- |
|||
| ? | 885081086 | • GLASS, WARNING LIGHT | 1 | SN: 8901442- |
|||
| ? | 885141098 | • GLASS, CHECK SAFETY LAMP | 1 | SN: 8901442- |
|||
| ? | 885081092 | • SWITCH, EMERGENCY | 1 | SN: 8901442- |
|||
| ? | 885141101 | • GLASS, EMERGENCY | 1 | SN: 8901442- |
|||
| ? | 885081094 | • SWITCH | 1 | SN: 8901442- |
|||
| ? | 885141099 | • GLASS, HEATER | 1 | SN: 8901442- |
|||
| ? | 885411096 | • CONNECTOR | 5 | SN: 8901442- |
|||
| ? | 885411100 | • SWITCH HOLDER | 2 | SN: 8901442- |
|||
| ? | 885081089 | • SWITCH | 1 | SN: 8901442- |
|||
| ? | 885141107 | • GLASS, FRONT WORKING LIGHT | 1 | SN: 8901442- |
|||
| ? | 885081090 | • SWITCH, WIPER | 1 | SN: 8901442- |
|||
| ? | 885141104 | • GLASS, WIPER | 1 | SN: 8901442- |
|||
| ? | 885411099 | • PLUG | 1 | SN: 8901442- |
|||
| ? | 885411187 | • HORN | 1 | SN: 8917808- |
|||
| ? | 885071034 | • RELAY | 1 | SN: 8917808- |
|||
| ? | 885081113 | • COMMUTATOR, ASSY. | 1 | SN: 8901442- |
|||
| ? | 312208059 | • COMMUTATOR | 1 | SN: 8901442- |
|||
| ? | 312208613 | • UPPER COVER | 1 | SN: 8901442- |
|||
| ? | 312208612 | • COVER | 1 | SN: 8901442- |
|||
| ? | 801104043 | • SCREW | 2 | SN: 8901442- |
|||
| ? | 801104050 | • SCREW | 2 | SN: 8901442-8905901; 8901442- |
|||
| ? | 802120005 | • SPRING WASHER | 2 | SN: 8901442-8905901; 8901442- |
|||
| ? | 885270201 | WIRING HARNESS, ASSY. | 1 | SN: 8901442-8905901; 8901442-8917801 |
A | ||
| ? | 885270509 | WIRING HARNESS, ASSY. | 1 | SN: 8901442-8905901; 8917808- |
B | ||
| ? | CTK100310 | GEARBOX DRIVE, ASSY. | 1 | SN: 8901442-8905901; 8901442-8905901 |
A | ||
| ? | (CK4224986) | GEARBOX DRIVE, ASSY. | 1 | SN: 8901442-8905901; 8905908- |
B | ||
| ? | CK4201700 | • KNOB | 1 | SN: 8901442-8905901; 8901442-8905901 |
|||
| ? | CK4201684 | • PEG | 1 | SN: 8901442-8905901 |
|||
| ? | CK4201696 | • BELOWS | 1 | SN: 8901442-8905901 |
|||
| ? | CK4201716 | • GASKET | 1 | SN: 8901442-8905901 |
|||
| ? | CK4201629 | • COVER | 1 | SN: 8901442-8905901 |
|||
| ? | CK4201625 | • ADAPTOR | 1 | SN: 8901442-8905901 |
|||
| ? | 801104050 | SCREW | 2 | SN: 8901442- |
|||
| ? | 802070005 | WASHER | 2 | SN: 8901442- |
|||
| ? | SEE FIG. 1415 | SN: 8905908- |
1415 | ||||
| ? | SEE FIG. 5100 | 5100 |
