| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 801852216 | NUT | 4 | SN: 8901442- |
|||
| ? | 802060016 | WASHER | 4 | SN: 8901442- |
|||
| ? | 808001031 | DAMPER | 4 | SN: 8901442- |
|||
| ? | 312207076 | SUPPORT, FRONT, R.H. | 1 | SN: 8901442- |
|||
| ? | 801014198 | BOLT | 4 | SN: 8901442- |
|||
| ? | 801014130 | BOLT | 13 | SN: 8901442- |
|||
| ? | 802150012 | SPRING WASHER | 13 | SN: 8901442- |
|||
| ? | 312207075 | SUPPORT, FRONT, L.H. | 1 | SN: 8901442- |
|||
| ? | 871120117 | ASPIRATED ENGINE | 1 | SN: 8901442- |
|||
| ? | 885070015 | WATER TEMPERATURE TRANSMITTER | 1 | SN: 8901442- |
|||
| ? | 360707628 | ADAPTOR | 1 | SN: 8901442- |
|||
| ? | 801050158 | BOLT | 8 | SN: 8901442- |
|||
| ? | 802150510 | SPRING WASHER | 8 | SN: 8901442- |
|||
| ? | 807001160 | DRIVE SHAFT, ASSY. | 1 | SN: 8901442-8905901 |
A | ||
| ? | 807001168 | DRIVE SHAFT, ASSY. | 1 | SN: 8905908-8909548; 8913139-8913139; 8913153-8913160 |
B | ||
| ? | 807001170 | DRIVE SHAFT, ASSY. | 1 | SN: 8909555-8913132; 8913146-8913146; 8913167- |
C | ||
| ? | 802150510 | SPRING WASHER | 12 | SN: 8901442- |
|||
| ? | 801014095 | BOLT | 12 | SN: 8901442- |
|||
| ? | 312207077 | SUPPORT, REAR, R.H. | 1 | SN: 8901442-8909548 |
A | ||
| ? | 312207119 | SUPPORT, REAR, R.H. | 1 | SN: 8909555- |
B | ||
| ? | 312207652 | SUPPORT, REAR, L.H. | 1 | SN: 8901442- |
|||
| ? | CK4200573 | SENSOR, REVOLUTION | 1 | SN: 8901442-8905901 |
A | ||
| ? | CK4202485 | SENSOR, REVOLUTION | 1 | SN: 8905908- |
B | ||
| ? | CK0030020 | O-RING | 1 | SN: 8901442-8905901 |
A | ||
| ? | CKK030022 | O-RING | 1 | SN: 8905908- |
B | ||
| ? | CK4200589 | CONNECTOR | 1 | SN: 8901442-8905901 |
|||
| ? | 802660500 | HOSE-CLAMP | 1 | SN: 8901442- |
|||
| ? | 802070010 | WASHER | 1 | SN: 8901442- |
|||
| ? | 801014093 | BOLT | 1 | SN: 8901442-8905901; 8901442- |
|||
| ? | P2848A102 | HIGH TEMPERATURE TRANSMITTER | 1 | SN: 8901442- |
|||
| ? | CK4202488 | SUPPORT | 1 | SN: 8901442-8905901; 8905908- |
|||
| ? | CK03GM612 | SCREW | 1 | SN: 8901442-8905901; 8905908- |
