| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 312207093 | RADIATOR, ASSY. | 1 | SN: 8901442-8902282 |
A | ||
| ? | 312207095 | RADIATOR, ASSY. | 1 | SN: 8902289-8905355 |
B | ||
| ? | 875001119 | • OIL COOLER | 1 | SN: 8901442-8905355 |
|||
| ? | 500351741 | UNION | 1 | SN: 8902289-8905355; 8901442-8905355 |
|||
| ? | 855051217 | • O-RING | 1 | SN: 8901442-8905355 |
|||
| ? | 852110018 | HOSE | 1 | SN: 8901442-8905355 |
|||
| ? | 855150078 | GASKET | 1 | SN: 8901442-8902282 |
|||
| ? | 500361341 | EXTENSION | 1 | SN: 8901442-8902282 |
|||
| ? | 500352106 | ELBOW | 1 | SN: 8901442-8905355 |
|||
| ? | 855051217 | • O-RING | 1 | SN: 8901442-8905355 |
|||
| ? | 392011090 | HOSE | 1 | SN: 8901442-8905355 |
|||
| ? | 312210621 | HOSE | 2 | SN: 8901442-8905355 |
|||
| ? | 801014094 | BOLT | 1 | SN: 8901442-8905355 |
|||
| ? | 802150510 | SPRING WASHER | 1 | SN: 8901442-8905355 |
|||
| ? | 312210617 | U-BOLT | 1 | SN: 8901442-8905355 |
|||
| ? | 500355908 | UNION | 1 | SN: 8901442-8905355 |
|||
| ? | 312207695 | UNION | 1 | SN: 8901442-8905355 |
|||
| ? | 845380008 | VALVE, ASSY. | 1 | SN: 8901442-8905355 |
|||
| ? | 200364906 | UNION | 1 | SN: 8901442-8905355 |
|||
| ? | 855051217 | • O-RING | 1 | SN: 8901442-8902282; 8901442-8905355 |
|||
| ? | 500365506 | PLUG | 2 | SN: 8901442-8905355 |
|||
| ? | 855150063 | GASKET | 2 | SN: 8901442-8905355 |
|||
| ? | 500365508 | PLUG | 1 | SN: 8901442-8902282; 8901442-8905355 |
|||
| ? | 855150078 | GASKET | 1 | SN: 8901442-8905355 |
|||
| ? | 392011064 | HOSE | 1 | SN: 8901442-8905355 |
|||
| ? | 500351741 | UNION | 1 | SN: 8901442-8905355 |
|||
| ? | SEE FIG. 6000 | 6000 | |||||
| ? | SEE FIG. 6510 | 6510 |
